Full Colour RGB+CW High Power ColourStrip

Our premium RGBW Led Strip with a higher density (96 LED's per metre), and a higher power output so that when you need a truly vibrant colour changing performance, it can deliver. Adding a true cool white chip to RGB means better colour control, more pastel colours, a much wider colour palette, as well as true white capability - the results are obvious, much greater subtlety and more effective light.

A heavy-duty 3oz PCB means better thermal control for enhanced long- term reliability and can be run in lengths up to a generous 10m single run, without voltage drop.

All ColourStrip products are supplied with 3M VHB (Very High Bond) adhesive tape on the rear meaning once fitted it will not sag, delaminate or just fall off.

Important - remember that to make this work you will need the following additional items

• A Dimming Interface

• A Power Supply
• 5 Core Cable

Power Supply - The  maximum power consumption is 20w per metre.  Choose a power supply with enough capacity - Powerpro75 is OK for up 3m and Powerpro150 will power 7m.

If you wish to to use long lengths then you should inject the power in the centre of the length rather than the end - this will avoid voltage drop and uneven light output.

Please note that solderless connectors are not available for this strip, the connection of the cable to the strip must be a soldered connection - we recommend that you use our soldering option.

This product should always be used with an aluminium mounting profile to manage heat and provide long, reliable life.

Priced per metre.

Specification

• IP Rating: IP21
• Max Wattage: 20w per metre
• Voltage: 24V
• Colour Temperature: RGB + 6000k Cool White
• Number of LEDs: 96 per metre
• Tape Width: 12mm
• Cut Points: Every 62mm
• Maximum Run Length: 10m

Downloads

Installation Instructions
