Maxilux 75w LED Power Supply 24v
A power supply for any 24v LED Strip
Seamless : recommended max length 8m
ProStrip : recommended max length 5m
ColourStrip : recommended max length 4m
Adjustable Colour Temperature : recommended max length 5m
Designed for long term reliability and safety, this unit has built in protection against : Open Circuit, Short Circuit, Over Load and Over Heat. These units are not dimmable - if you wish to dim the LED strip then you must place a dimmer on the low voltage side.
The primary/input end is marked with a Live and Neutral terminal to connect to a 200-/240v AC current. The secondary output side has a DC cable for easy assembly to LED Strip. This can easily be removed for a direct connection or to connect to the Cables & Connectors system, use product code LV-CS07.
It is SELV marked and has Class II Protection for protection against electric shock from direct and indirect currents with a fail-safe transformer.
Double insulated and suitable for installation or attachment to furniture with all flammable properties.
Customer Reviews
Does what it’s supposed to do.
First time using this product and the company was very helpful and on hand to expain how to install very quickly and simply
Follow and tag us at @LEDSpaceLighting
Product Q&A
-
I am looking to drive 4x1m strips will one drive do this?
Hi, Yes this is possible, you may require a terminal block as the terminals on the power supply may struggle to receive 4 cables.
-
I am looking to drive two separate 2m strips of NoSpot Line10 6000K Cool White COB LED Strip Lights from an existing wall switch do I need one or two LED Power Supplies
HI, you can run 2 strips from one power supply no problem, for this I would recommend you use a 75w power supply
-
What size fuse should I place in the mains plug to safely run this unit?
A 5amp should plenty.
-
Hi, what is the dimensions of the unit?
Hi,
Please see below dimensions of the unit:
16.5cm x 5.5cm, deepth 3cm.
